1 |
Model |
|
FBR10-MJZ |
FBR13-MJZ |
FBR15-MJZ |
FBR18-MJZ |
FBR20-MJZ |
1 |
| 2 |
Power |
|
battery |
2 |
| 3 |
Operation |
|
stand-on |
3 |
| 4 |
Rated load capacity |
Q（㎏） |
1000 |
1300 |
1500 |
1800 |
2000 |
4 |
| 5 |
Rated lift height |
h3(㎜) |
3000 |
5 |
| 6 |
Load centre |
C(㎜) |
500 |
6 |
| 7 |
Fork carriage tilt（forward /backward） |
α/β(deg) |
3/5 |
7 |
| 8 |
Travel speed（with/without load） |
(km/h) |
8/8.5 |
8/8.5 |
8.8/9.3 |
8.5/9.3 |
8.2/9 |
8 |
| 9 |
Lifting speed（laden） |
(㎜/s) |
160 |
150 |
240 |
230 |
220 |
9 |
| 10 |
Max gradeability（laden） |
（%） |
>12 |
>12 |
>10 |
10 |
| 11 |
Min turning tadius |
wa(㎜) |
1430 |
1500 |
1580 |
1660 |
1700 |
11 |
| 12 |
Reach distance |
X（㎜） |
580 |
650 |
500 |
550 |
600 |
12 |
| 13 |
Wheel base |
Y（㎜） |
1110 |
1180 |
1370 |
1420 |
1470 |
13 |
| 14 |
Service brake |
|
|
|
mech |
14 |
 |
15 |
Overall length |
l1(㎜) |
1820 |
1870 |
2057 |
2107 |
2187 |
15 |
| 16 |
Main body length |
l2(㎜) |
955 |
1257 |
16 |
| 17 |
Overall width |
b1(㎜) |
1020 |
1200 |
17 |
| 18 |
Height of mast,lowered |
h1(㎜) |
2080 |
2120 |
18 |
| 19 |
Free lift height |
h2(㎜) |
330 |
330 |
19 |
| 20 |
Height of mast,extended |
h4(㎜) |
3945 |
4000 |
20 |
| 21 |
Height of overhead guard |
h5(㎜) |
2160 |
2160 |
21 |
| 22 |
Fork dimensions |
s×e×l（㎜） |
35×100×900 |
35×120×900 |
45×120×900 |
22 |
| 23 |
Min ground clearance |
h6(㎜) |
80 |
80 |
23 |
| 24 |
Aisle width with pallet（1200×1200） |
Ast1(㎜) |
2650 |
2700 |
2900 |
2980 |
3020 |
24 |
| 25 |
Aisle width with pallet（1000×1000） |
Ast2(㎜) |
2430 |
2500 |
2700 |
2780 |
2820 |
25 |
| 26 |
Service weight |
（㎏） |
1700 |
1800 |
2550 |
2650 |
2800 |
26 |
 |
27 |
Drive motor |
（Kw） |
2.2 |
3.7 |
27 |
| 28 |
Lift motor |
（Kw） |
2 |
8.2 |
28 |
| 29 |
Battery:voltage/capacity（5h） |
（V/Ah） |
24/390 |
48/450 |
29 |
 |
30 |
Tyres |
|
solid tyre |
polyurethane/solid tyre |
30 |
| 31 |
Size of front tyre |
|
250×71 |
250×120 |
250×120 |
31 |
| 32 |
Size of rear tyre |
|
381×120 |
381×120 |
32 |
| 33 |
Size of balancing tyre |
|
170×70 |
170×70 |
33 |
| 34 |
Track width front |
b2(㎜) |
950 |
1080 |
34 |
| 35 |
Track width rear |
b3(㎜) |
506 |
580 |
35 |
 |
36 |
Turning system |
|
mech |
hyd |
36 |
| 37 |
Speed control system |
|
CurTis DC/ZAPI AC |
37 |
