SCZ30-4D伸縮臂吊裝機
（Telescopic Crane Loader）
[ 產品簡介 Product Introduction ]
SCZ30-4D型伸縮臂吊裝機，底盤采用四輪驅動，剛性懸掛；液力機械傳動，液壓動力轉向和液壓制動，后輪轉向。作業裝置為兩節四邊形伸縮式工作臂和吊臂，專用于進集裝箱石板材的吊裝作業。
該車根據用戶需求，在SCZ35-4型基礎上，對工作臂、油缸及前后驅動橋、車架等均進行加強型設計，使用性能可靠。產品投放市場后，用戶反映良好。
The Telescopic Crane Loader (SCZ30-4D) for almost any task that involves lifting, moving or placing objects or materials. It works with Four-Wheel Drive, hydromechanical transmission, hydraulic Power Steering, Hydraulic brake, and Rear-Wheel Steering. The handling equipment are Telescopic boom and Craner, it is expert to handle the stone-slab in container.
As the customers’request, we upgrade the design of SCZ35-4 with the working boom, cylinder and the shaft of drive etc. The quality is stable. It takes good reflection from the customers after marketing.
[ 主要技術參數 Specifications ]
|
額定起重量 Rated Load |
| |
|
載荷中心距（輪胎前沿距載荷中心） The Distance of Load Center(Tyre-fore to load center) |
| |
|
主鉤最大起升高度（主吊鉤距地面） Max.Lifting Height of Main Hook(Main hook to ground) |
| |
|
主鉤最大外伸距（水平）（輪胎前沿距主吊鉤） Max.Outspread of Main Hook(Horizontal)(Tyre-fore to main hook) |
| |
|
最大行駛速度 Max.Traveling Speed |
| |
|
最小離地間隙 Min.Ground Clearance |
| |
|
最小轉彎半徑 Min.turning Radius |
| |
|
爬坡度 Grade Ability |
≥30% | |
|
傾翻角度上/下 The Angle of Lean Up/Down |
15°/25° | |
|
輪距 Tread |
| |
|
軸距 Wheel base |
| |
|
自重 Deadweight |
| |
|
整機外形尺寸（長×寬×高）（不計屬具高度） Overall Dimension (L×W×H)(Except the tool’s) |
| |
|
發動機（東風康明斯） Engine (Dongfeng Cummins) |
型號 Type |
4BT3.9-C80 |
|
額定功率 Rated power |
60kw | |
|
標定轉速 Rated speed |
2000r/min | |
|
排量 Exhaust |
| |
|
輪胎 |
前輪 Front wheel |
16/70-24(14PR) |
|
后輪 Rear wheel |
10.00-20(14PR) | |
注：由于技術改進，該數據可能與產品不符，如有誤則以產品為準。
Note:The content and performance will be revised and the products will be improve without notice.
